Kitronik Stereo Amplifier

Description

• Kitronik Stereo Amplifier
• Offers 1W per channel stereo amplifier
• Uses an NJM2073D audio amplifier IC
• Works nicely off a 9 V battery (not supplied)
• Supplied with two speakers and a pre-made 3.5 mm jack plug
• Note: This kit is also available as a pre-built version

The Kitronik Stereo Amplifier can be used with any personal stereo equipment, including MP3 players. It uses an NJM2073D audio amplifier IC which can output 1W per channel.

The kit is supplied with two speakers and a pre-made 3.5 mm jack plug. It works nicely off a 9 V battery (not supplied) or if you want to run it off the mains why not try the 12V wall power unit (not included)

View moreWhat’s Included

• 1 x NJM2073D Stereo Amplifier IC
• 1 x 8 Pin IC Holder
• 2 x 10K Resistors
• 2 x 4.7R Resistors
• 2 x 100K Resistors
• 2 x Ceramic Capacitor, 50 V, 100 nF
• 2 x Electrolytic Capacitor, 16 V, 470 uF
• 2 x Electrolytic Capacitor, 25 V, 100 uF
• 1 x Electrolytic Capacitor, 16 V, 10 uF
• 1 x Stereo Amp Cable
• 1 x PP3 Battery Clip Lead (Heavy Duty)
• 2 x 8 Ohm 66 mm Speaker
• 2 x 1 m Figure 8 Speaker Cable (7×0.18 mm)
• 1 x Stereo Amplifier PCB

Dimensions

Size

• 58 x 35 mm (L x W)

Links

PDF File

• Kitronik Stereo Amplifier – Datasheet

Specifications

• PCB Component Count: 21
• Voltage Nominal: 9 V
• Voltage Range: 2 – 15 V
• Standby Current: 7.5 mA
• Current Max at Nominal Voltage: 180 mA
