Description
- Dagu Robot Digital Shake Sensor Module
- Designed for Arduino (Not Included)
- Adopted spring-type vibration switch
- Working voltage: 3.3 V ~ 5 V
- Output type: digital signal
- Interface mode: pH2.0~3P
The Dagu Robot Digital Shake Sensor Moduleis sensitive only to one-way hand movement. Spring-type vibration switch is adopted. When the external force shakes, the conducting needle will be opened instantaneously when the appropriate shaking force is achieved.
Only horizontal shaking can be detected. You can use digital read () to get the high and low levels of the module, but because the opening time is very short, it is better to use an interrupt to capture the effect. The module keeps high-level output at ordinary times and outputs low-level when shaking.
View moreWhat’s Included
- 1x Dagu Robot Digital Shake Sensor Module
Dimensions
Size
Specifications
- Working voltage: 3.3 V ~ 5 V
- Output type: digital signal
- Interface mode: pH2.0~3P
- Weight: 42 g
