Description
Raykha S8 comprises 8 units of TCRT5000 (Reflective Optical Sensor IR LED/phototransistor) pairs mounted on a 10mm pitch, This arrangement makes a it a great detector for line-following robots. Each sensor is having its own Digital I/O measurable output , variable voltage analog output and an indication LED.
Features
Model : Raykha S8
IR sensor : TCRT5000
Indication : Red SMD LEDs x 8
Channels : 8
Pitch : 10mm
Supply voltage : 5V DC
Supply current : 200mA max
Digital Outputs : 8
Analog Outputs : 8
PCB Size : 78.00mm x 25.00mm
Functional Description
Raykha Reflective sensor array is intended as a line sensor, but it can also be used as a general-purpose proximity or reflective sensor. To work with the Module following procedure to be followed.
1. Mount the sensor module
2. Provide power (5V DC)
2. Adjust the preset for the color variation
View moreWhat’s Included
1 Unit of Raykha S8
Right angle male header
Straight male header
Dimensions78.00mm x 25.00mm x 25mmLinksAttached files
Specifications
Model : Raykha S8
IR sensor : TCRT5000
Indication : Red SMD LEDs x 8
Channels : 8
Pitch : 10mm
Supply voltage : 5V DC
Supply current : 200mA max
Digital Outputs : 8
Analog Outputs : 8
